Docker Bridge and Overlay Network with Compose Variable Substitution

Arun GuptaDecember 10th, 2015Last Updated: December 10th, 2015

0 51 2 minutes read

Docker Multi-Host networking allows you to create virtual networks and attach containers to them so you can create the network topology that is right for your application. Bridge networks can be created for single host and overlay networks can be created for multiple hosts. Creating application-specific networks provides complete isolation for containers.

Docker Compose file can be targeted at a single host, and --x-networking will create a bridge network exclusive for the application. If the sample application is targeted at multiple hosts, say using Docker Swarm cluster, then an overlay network is created. Single host networking and multi host networking provide more details on how to set this up.

What if a bridge or an overlay network already exists and you’d like to assign this to your application started using Docker Compose?

Docker 1.9 introduced variable substitution, and we can use that feature to target an application to a pre-created network.

Create New Docker Bridge Network

Create a new network:

docker network create -d bridge mynet
47d6225ffe56ddd1a8bc0d6abb0ffd8f8ac3eec2090ff243f8cd6f77c170751b=

List the networks:

docker network ls
NETWORK ID          NAME                DRIVER
feb6e9567439        bridge              bridge
29563a59abe8        none                null
25ab737cd665        host                host
47d6225ffe56        mynet               bridge

Docker create three networks for each host automatically:

NETWORK NAME	PURPOSE
`bridge`	Default network that containers connect to. This is `docker0` network in all Docker installations.
`none`	Container-specific networking stack
`host`	Adds a container on hosts networking stack. Network configuration is identical to the host.

In addition, you also see mynet network that was just created.

Inspect the newly created network using docker network inspect mynet:

[
    {
        "Name": "mynet",
        "Id": "47d6225ffe56ddd1a8bc0d6abb0ffd8f8ac3eec2090ff243f8cd6f77c170751b",
        "Scope": "local",
        "Driver": "bridge",
        "IPAM": {
            "Driver": "default",
            "Config": [
                {}
            ]
        },
        "Containers": {},
        "Options": {}
    }
]

No containers are assigned to it yet.

Docker Compose and Networking

This new network can be used for any new container using docker run --net=<NETWORK> command. This blog will show how to target this network to a Compose file:
```
mycouchbase:
  container_name: "db"
  image: couchbase/server
  ports:
    - 8091:8091
    - 8092:8092
    - 8093:8093
    - 11210:11210
  net: ${NETWORK}
mywildfly:
  image: arungupta/wildfly-admin
  environment:
    - COUCHBASE_URI=db
  ports:
    - 8080:8080
    - 9990:9990
  net: ${NETWORK}
```
Note how net is specified here to use a custom network. This Compose file is at: github.com/arun-gupta/docker-images/blob/master/wildfly-couchbase-javaee7-network/docker-compose.yml.
Start the application, using our newly created network, as:
```
NETWORK=mynet docker-compose up -d
```

Inspect the network again:

docker network inspect mynet
[
    {
        "Name": "mynet",
        "Id": "47d6225ffe56ddd1a8bc0d6abb0ffd8f8ac3eec2090ff243f8cd6f77c170751b",
        "Scope": "local",
        "Driver": "bridge",
        "IPAM": {
            "Driver": "default",
            "Config": [
                {}
            ]
        },
        "Containers": {
            "300bebe6c3e0350ebf9b9d3746eb3a7b49444e14c00314770627a9f101442639": {
                "EndpointID": "82a3e2d7cd4f1bb03c9ef52bb6abf284942d7e9fcac89fe3700b0e0c4ed2654f",
                "MacAddress": "02:42:ac:14:00:03",
                "IPv4Address": "172.20.0.3/16",
                "IPv6Address": ""
            },
            "4fdae4eb919f0934422513227fe541255557dd9e8b3317374685927e7f427249": {
                "EndpointID": "937605d716d144b55288d70817d611da5fb0f87e3aedd6b5074fca07f82c3953",
                "MacAddress": "02:42:ac:14:00:02",
                "IPv4Address": "172.20.0.2/16",
                "IPv6Address": ""
            }
        },
        "Options": {}
    }
]

And now the two containers are assigned to this network as well.

Check the container id using docker ps:

CONTAINER ID        IMAGE                     COMMAND                  CREATED             STATUS              PORTS                                                                                               NAMES
300bebe6c3e0        couchbase/server          "/entrypoint.sh couch"   2 minutes ago       Up 2 minutes        0.0.0.0:8091-8093->8091-8093/tcp, 11207/tcp, 11211/tcp, 0.0.0.0:11210->11210/tcp, 18091-18092/tcp   db
4fdae4eb919f        arungupta/wildfly-admin   "/opt/jboss/wildfly/b"   2 minutes ago       Up 2 minutes        0.0.0.0:8080->8080/tcp, 0.0.0.0:9990->9990/tcp                                                      wildflycouchbasejavaee7network_mywildfly_1

Check the network for one container:

docker inspect -f '{{ .HostConfig.NetworkMode }}' 300
mynet

More details about the network:


docker inspect -f '{{ .NetworkSettings.Networks.mynet }}' 300
{82a3e2d7cd4f1bb03c9ef52bb6abf284942d7e9fcac89fe3700b0e0c4ed2654f 172.20.0.1 172.20.0.3 16   0 02:42:ac:14:00:03}

More details about the container can be found using docker inspect, relevant portion is shown here:


"Networks": {
    "mynet": {
        "EndpointID": "82a3e2d7cd4f1bb03c9ef52bb6abf284942d7e9fcac89fe3700b0e0c4ed2654f",
        "Gateway": "172.20.0.1",
        "IPAddress": "172.20.0.3",
        "IPPrefixLen": 16,
        "IPv6Gateway": "",
        "GlobalIPv6Address": "",
        "GlobalIPv6PrefixLen": 0,
        "MacAddress": "02:42:ac:14:00:03"
    }
}

Create New Docker Overlay Network

Creating a new Docker overlay network requires to setup a key/value service and a Docker Swarm cluster. Multi-host and multi-container blog provide more details on that.
